Sim900A GSM Module

Sim900A GSM Module

28,000 MMK

SKU Code

MD0028

Availability

Out Of Stock

Categories

  • Modules

Description

The SIM900A is a readily available GSM/GPRS module,used in many mobile phones and PDA. The module can also be used for developing IOT (Internet of Things) and Embedded Applications. SIM900A is a dual-band GSM/GPRS engine that works on frequencies EGSM 900MHz and DCS 1800MHz. SIM900A features GPRS multi-slot class 10/ class 8 (optional) and supports the GPRS coding schemes CS-1, CS-2, CS-3 and CS-4.

Specifications

  • Single supply voltage: 3.4V – 4.5V
  • GSM class: Small MS
  • GPRS connectivity:GPRS multi-slot class 10 (default) , GPRS multi-slot class 8 (option) Transmitting power: Class 4 (2W) at EGSM 900, Class 1 (1W) at DCS 1800
  • Operating Temperature: -30ºC to +80ºC
  • Storage Temperature: -5ºC to +90ºC
  • DATA GPRS: download transfer max is 85.6KBps, Upload transfer max 42.8KBps
  • Supports CSD, USSD, SMS, FAX
  • Supports UART interface
  • Supports single SIM card
  • Communication by using AT commands
